| Model Number: | JZD-P16 |
| MOQ: | 1 |
| Price: | €3,035.16 |
| Operating voltage | 220 VAC (+/-10%, 50/60 Hz) |
| Input current | 80/160 mA |
| Ambient temperature | -10/60 degrees |
| Case Material | Stainless Steel |
| Contact parts with material | PP plastic and PTFE |
| Compressed air | 4-8 kg, connected with 6-8 mm hose |
| Gas consumption | 0.6 liters each separate action |
| Level of protection | IP 54 |
| Separation time | 0.2 - 2.5 seconds (No level adjustment) |
| Detection accuracy | 0-10 stepless adjustable (recommended scale 9) |
| Detection method | Plastic granules with falling body |
| Material characteristics | Dry, no long-fiber, non-conductive, particles less than 8 mm |
| Model Type | Internal Detection Tube Diameter | Capacity (l/h) | Detection Accuracy |
|---|---|---|---|
| 80 Type | 80 mm | 5,000 | Iron/Stainless Steel: 0.7 mm, Copper: 1.2 mm |
| 100 Type | 100 mm | 10,000 | Iron/Stainless Steel: 0.8 mm, Copper: 1.5 mm |
| 150 Type | 150 mm | 20,000 | Iron/Stainless Steel: 1.2 mm, Copper: 2.0 mm |
| 200 Type | 200 mm | 40,000 | Iron/Stainless Steel: 1.5 mm, Copper: 2.0 mm |
| 250 Type | 250 mm | 65,000 | Iron/Stainless Steel: 2.0 mm, Copper: 2.5 mm |
