| Model Number: | JZD-88 |
| MOQ: | 1 |
| Parameter | Specification |
|---|---|
| Model | JZD-366 |
| Width of Inspection Window (mm) | 400 (customization available) |
| Height of Inspection (mm) | 100 | 120 | 150 | 200 | 250 | 300 | 350 | 400 |
| Detection Sensitivity - Fe (Φmm) | ≥0.6 | ≥0.8 | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 |
| Detection Sensitivity - Non-Fe (Φmm) | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | ≥4.5 |
| Detection Sensitivity - 304SUS (Φmm) | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | ≥4.5 |
| Alarm System | Audible and visual alarm, automatic stop |
| Raw Material | SUS304 |
| Normal Machine Size (mm) | 160(L)cm × 90(W)cm × 100(H)cm (Based on normal size) |
| Net Weight | 330kg (based on normal size) |
| Electrical Source (Power) | 110V/220V/380V 50Hz/60Hz (Power) 90W |
| Conveyor Speed | 25-30m/min (can be designed according to customer requirements) |
| Conveyor Height | 650mm±50mm (normal) can be manufactured according to customer needs |
